Bimetal composite wear-resisting steel plate Easily for cutting
welding bending
Bimetal composite wear-resisting steel plate is composed of low
carbon steel plate and alloy wear-resisting layer, and the
anti-wear layer generally accounts for 1/3-1/2 of the total
thickness. When working, the matrix provides comprehensive properties such as
strength, toughness and plasticity to resist external forces, and
the wear-resisting layer provides wear-resisting properties to meet
the requirements of specified working conditions.
Wear-resisting steel plate alloy wear-resisting layer and matrix is
metallurgical bonding. Through special equipment, using automatic welding process, the
high hardness self-protection alloy welding wire evenly on the base
material. The number of composite layers is from one layer to two layers and
even several layers. In the composite process, uniform transverse
cracks appear because of the different alloy shrinkage ratio, which
is a significant feature of wear-resisting steel plate.
Wear resistant layer is mainly chromium alloy, but also add
manganese, molybdenum, niobium, nickel and other alloy components,
the microstructure of carbide fiber distribution, fiber direction
and surface perpendicular. The microhardness of carbide can reach above HV1700-2000, and the
surface hardness can reach HRC 58-62. Alloy carbide has strong stability at high temperature, maintain
high hardness, but also has good oxidation resistance, within 500℃
completely normal use.
Good wear-resistant steel with high abrasion resistance and impact
performance is good, can be cutting, bending, welding, etc., can
adopt welding, plug welding, bolt connection way to connect with
other structures, such as the scene of the maintenance process
possesses the characteristics of time saving, convenient and widely
used in metallurgy, coal, cement, power, glass, mining, building
materials, brick and tile industry, compared with other materials, With high cost performance, it has been favored by more and more
industries and manufacturers
7. Comprehensive quality control.
Material | Thickness | Width | Length |
NM360 | 8 | 2200 | 8000 |
NM360 | 10 | 2200 | 8000 |
NM360 | 15 | 2200 | 8000 |
NM400 | 12 | 2200 | 8000 |
NM500 | 16 | 2200 | 8000 |
NM360 | 20 | 2200 | 10300 |
NM450 | 25 | 2200 | 12050 |
NM400 | 30 | 2200 | 8000 |
NM360 | 35 | 2090 | 10160 |
NM400 | 40 | 2200 | 8000 |
NM400 | 45 | 2200 | 8000 |
NM400 | 50 | 2200 | 8000 |
NM360 | 60 | 2200 | 7000 |
NM400 | 70 | 2200 | 9500 |
NM400 | 80 | 2200 | 8000 |
Wear-resisting plate generally has 3+3, 4+2, 5+3, 5+4, 6+4, 6+5,
6+6, 8+4, 8+5, 8+6, 10+5, 10+6, 10+8, 10+10, 20+20 and so on
Wear-resistant plate commonly used wire models: LZ570, LZ590,
LZ601, LZ606, LZ650, etc. (wire diameter: 2.4-3.2)
Product Description
Q: What kind of work does your company do?
A: Our company is a professional manufacturer and trader.
We mainly produces stainless steel plate/pipe/coil/round bars, as
well as aluminum plate/pipe/coil/bar.
Q: What advantages does your company have?
A:
(1) Prime quality and reasonable price.
(2) Wide excellent experiences with after-sale service.
(3) Every process will be checked by responsible QC which insures
every product's quality.
(4) Professional packing teams which keep every packing safely.
(5) Trial order can be done in one week.
(6) Samples can be provided as your requirements.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30%
T/T in advance, balance based on BL copy or LC at sight. If you
have another question, please contact us.
Q: What about your price?
A: Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.
Q: How long is your delivery time?
A: Different products have different delivery time. The products
will be delivered as soon as possible on the basis of the quality
assurance. Usually the delivery time is within5 days after we
received your deposit.
